PWAY 4 ports HDMI USB KVM Switch support 1080P 4 input 1 output

FOB Reference Price:Get Latest Price
  • 1 - 9 Sets
    US $65.00
  • 10 - 99 Sets
    US $55.00
  • >=100 Sets
    US $48.00
Report Suspicious Activity
Overview
Quick Details
Brand Name:
PWAY
Model Number:
PW-SH0401K
Place of Origin:
Guangdong, China (Mainland)
Standards:
HDMI 1.4;HDCP 1.2
Resolution range:
Up to 4Kx2K@30Hz, 3D, 1920*1080@60Hz
Power supply:
The power adapter: DC 5V
Interface protocols:
USB2.0
Output interface type:
USB-A
Connector:
HDMI-A Interface
Power dissipation:
MAX 3W
Dimension:
230*74*25mm
Operating Temperature/Humidity:
-5℃ ~ +70℃/5% ~ 90%
warranty:
1 year free warranty
Supply Ability
Supply Ability:
1000 Set/Sets per Week
Packaging & Delivery
Packaging Details
Weight: 0.78 kg
Package size: 230*74*25mm
Package: Gift box
Port
Shenzhen

Description

HDMI KVM switch four groups of high-definition video source and USB interface implementation free switch, Adaptive EDID/HDCP decryption, can adapt to a variety of complex application environments.The equipment has excellent image processing and transmission capacity, make the output signal is more smooth and steady, is a reliable, high performance and efficient way of HDMI USB switch



Features

The four-way HD video source choose USB interface to realize four free switch;

Support video resolution max up to 4Kx2K@30Hz;

Compliance with HDMI 1.4 standard;

Adaptive EDID/HDCP decryption, able to adapt to a variety of complex application environment;

Hot key switch, convenient and quick(Scroll Lock + Scroll Lock+ 1,2,3,4)

HDCP 1.2 standard - high-bandwidth digital content protection technology;

High compatibility, can auto-match source and display device;

Built-in automatic adjustment system, make the image smooth, clear and stable;

Built-in ESD protection system;

Simple to install, plug and play;



Specifications

Parameter

Description

Video

Standards

HDMI 1.4;HDCP 1.2

Maximum pixel clock

225MHz

Maximum data rate

10Gbps

Resolution range

Up to 4Kx2K@30Hz, 3D, 1920*1080@60Hz

Connector

HDMI-A Interface

Impedance

100Ω

HDMI Cable Range

<5M( Resolution: 1920*1080@60Hz)

USB

Interface protocols

USB2.0

PC input interface type

USB-B

Output interface type

USB-A

Other

Power supply

The power adapter: DC 5V

Power dissipation

MAX 3W

Temperature

Operating: -5 ~ +70

Humidity

Operating: 5% ~ 90%

Dimension

230*74*25mm

The warranty

1 year free warranty



Panel


Port name

Description

1

5V power supply input port

2

HDMI video output signal

3

PC1 group HDMI USB input

4

PC2 group HDMI USB input

5

PC3 group HDMI USB input

6

PC4 group HDMI USB input

7

PC1, PC2,PC3,PC4 switch buttons and status indicators

8

Power light

9

USB keyboard mouse connectors



Diagram




Package List



 HDMI KVM4*1Switcher host ..........1  pcs

 USB wire.............................. ..........4  pcs

 Power adapter................................1  pcs

 user manual ...............................................1  pcs.

Company Information

About US.jpg

cetification



FAQ

WHY DO YOU WANT TO CHOOSE OUR PRODUCT?

1.We are manufacturer specialize in producing HDMI,DVI,VGA,S-VIDEO,AV transmitter and receiver,

converter series products.

2.Quality is our culture. Pwaytek people always attached great importance to quality controlling  from start

to finish.

3.We think our product will give an edge over your conpetitors.

4.If we are honor to become your supplier in China, you will enjoy the best after-sales service.

5.We can provide good service for many large company,such as   Goldman Sachs.

Where is your factory ? Can I have a visit?

Add:5/Floor,Mantong Building,Dafu Road ,Aobei Community ,Guanlan Street,Longhua District,Shenzhen,Guangdong Province, China

, SHEN ZHEN SHI PIN WEI TECHNOLOGY LIMITED



Can I buy samples from your company?

We can provide samples .Contact me to talk about the details please.



How about the payment terms?

We accept paypal ,T/T, Western Union......
